HONMA

BERES

BERES IE-05 Iron

TECHNOLOGY

E-05
  • Player who would like to swing aggressively.
  • Player wwants for straighter shots.
  • Player who would like to reduce slices for longer distance.
  • Player who would like to gain distance with shaft flexibility.

The unique irons made with the suitable designed parts

New idea, weight distribution to sole/heel
Irons having the head mechanism with the greatest grip, which transfers maximum energy to the ball.
New face strucuture(#5-#8)
The new face strucuture expands the repulsion area with a larger head. It's best suited for the target golfers who cannot hit down on the ball.
Optimum center of gravity provided by new sole thickness design
The new sole design with a thicker bottom and leading edge provides an extreme low and deep center of gravity. Ball is easier to lift and grip.

Structural drawings

Weight distribution
Weight distribution to heel By redistributing more weight to the heel and moving the center of gravity inward, we have made it easier to grip the ball, which leads to higher ball speeds.

The New face strucuture (#5-#8).

The new face strucuture is expanded to the lower portion of the face. The number of mishits by variation of impact is reduced. The thicker sole of the back provides the low/deep center of gravity. This design allows you to easily hit shots with high trajectory.
New sole thickness design

New sole thickness design

The new sole design with a thicker bottom and leading edge provides an extreme low and deep center of gravity. This makes it easy to get shots airborne.

Larger face size

The face of the toe/heel is 1 mm higher than IE-03, providing the expanded repulsion area, comfort and easy-to-address shape.
The face of the toe/heel is 1 mm higher than IE-03.
Compared to the previous model
Compared to the previous model

SPEC

Head material/Manufacturing process SUS630/Casting(body)・ Maraging stainless steel(face)
Head plating Double-layer plating / Satin finish + Painted finish
Shaft ARMRQ∞ 39
# (No.) 5 6 7 8 9 10 11 SW
Length(inches) 37.0 36.5 36.0 35.5 35.0 34.5 34.0 34.0
Loft (deg.) 24.0 27.0 30.0 34.0 38.0 43.0 49.0 56.0
Lie angle (deg.) 61.0 61.5 62.0 62.5 63.0 63.0 63.0 63.5
Face progression（mm） 1.75 2.25 2.75 2.75 3.25 3.75 3.75 4.25
Distance to Center of Gravity(mm) 37.5 37.5 37.5 37.5 37.5 37.0 36.0 36.0
Height to Center of Gravity(mm) 20.5 21.0 21.0 22.0 22.5 23.0 22.5 22.5
Depth to Center of Gravity(mm) 5.0 5.0 5.0 4.5 4.0 3.5 3.0 2.5
Gravity Angle（deg.） 13.5 - - - - - - -
Swing weight・
Gross weight (g)		 ARMRQ∞ 39 L C0・324 C0・330 C0・336 C0・342 C0・349 C0・355 C1・363 C1・363

Data refers to the 2S grade

Made in Japan

2S 3S 4S

SHAFT

ARMRQ∞ 39
Material Carbon+eight-axisUD
Kick-point Low
Flex L
Butt diameter (mm) 14.3
Tip diameter (mm) 9.3
# (No.) 5 6 7 8 9 10 11 SW
Gross weight (g) 44.5 44.0 44.5 44.0 44.5 44.0 43.5 43.5
Torque (deg.) 3.85 3.78 3.71 3.64 3.57 3.50 3.43 3.43
Frequency (cpm) 241 248 255 262 269 276 283 283

Data refers to the 2S grade/1W shaft only

GRIP

Name BERES RubberⅢ
Material Rubber
Gross weight (g) 32
Size 57
