HONMA

BERES

BERES IE-05 Iron

TECHNOLOGY

E-05
  • Player who would like to swing aggressively.
  • Player wanting straighter shots.
  • Player who would like to reduce slices for longer distance.
  • Player who would like to gain distance with shaft flexibility.

The unique irons made with the suitable designed parts

New idea, weight distribution to sole/heel
Irons having the head mechanism with the greatest grip for target golfers, which transfers maximum energy to the ball.
New face strucuture(#5-#8)
The new face strucuture expands the repulsion area with a larger head. It's best suited for the target golfers who cannot hit down on the ball.
Optimum center of gravity provided by new sole thickness design
The new sole design with a thicker bottom and leading edge provides an extreme low and deep center of gravity. This makes it easy to get shots airborne.

Structural drawings

Weight distribution
Weight distribution to heel By redistributing more weight to the heel and moving the center of gravity inward, we have made it easier to grip the ball which leads to higher ball speeds.

The New face strucuture (#5-#8).

The new face strucuture is expanded to the lower portion of the face. The number of mishits by variation of impact is reduced. The thicker sole of the back provides the low/deep center of gravity. This design allows you to easily hit shots with high trajectory.
New sole thickness design

New sole thickness design

The new sole design with a thicker bottom and leading edge provides an extreme low and deep center of gravity. This design allows you to easily hit shots with high trajectory.

Larger face size

The face of the toe/heel is 1 mm higher than IE-03, providing the expanded repulsion area, comfort and easy-to-address shape.
The face of the toe/heel is 1 mm higher than IE-03.
Compared to the previous model
Compared to the previous model

SPEC

Head material/Manufacturing process SUS630/Casting(body)・ Maraging stainless steel(face)
Head plating Double-layer plating / Satin finish + Painted finish
Shaft ARMRQ∞ 44
# (No.) 5 6 7 8 9 10 11 SW
Length(inches) 38.0 37.5 37.0 36.5 36.0 35.5 35.0 35.0
Loft (deg.) 24.0 27.0 30.0 34.0 38.0 43.0 49.0 56.0
Head volume(°) 61.0 61.5 62.0 62.5 63.0 63.0 63.0 63.5
Face progression（mm） 1.75 2.25 2.75 2.75 3.25 3.75 3.75 4.25
Distance to Center of Gravity(mm) 37.5 37.5 37.5 37.5 37.5 37.0 36.0 36.0
Height to Center of Gravity(mm) 20.5 21.0 21.0 22.0 22.5 23.0 22.5 22.5
Depth to Center of Gravity(mm) 5.0 5.0 5.0 4.5 4.0 3.5 3.0 2.5
Gravity Angle（deg.） 13.5 - - - - - - -
Swing weight・
Gross weight (g)		 ARMRQ∞ 44 R C6・336 C6・342 C6・348 C6・354 C6・360 C6・366 C6・372 C7・374

Data refers to the 2S grade

Made in Japan

2S 3S 4S

SHAFT

Shaft
ARMRQ∞ 44
Material Carbon+eight-axisUD
Kick-point Low
Flex R
Butt diameter (mm) 14.5
Tip diameter (mm) 9.3
# (No.) 5 6 7 8 9 10 11 SW
Gross weight (g) 48.0 47.5 48.0 47.5 48.0 47.5 47.0 47.0
Torque (deg.) 3.68 3.61 3.54 3.47 3.40 3.33 3.26 3.26
Frequency (cpm) 251 258 265 272 279 286 293 293

Data refers to the 2S grade/1W shaft only

GRIP

Grip
Name BERES RubberⅢ
Material Rubber
Gross weight (g) 36.5
Size 60
